Beskrivning

AD Converter

• Converts analogue audio line signals and feeds them into a Dante network
• 96 kHz / 32 Bit
• Fully functional Dante interface
• Adjustable signal level: +4 dBu / 0 dBu / 0 dBV /-10 dBV (via Dante Controller)
• Frequency range: 20 – 20,000 Hz (-/+0.2 dB)
• Requires POE (Power over Ethernet) for operation (Class1 802.3af PoE)
• RJ45 metal plug with built-in LEDs
• Input: 6-pin Euroblock
• Robust housing
• Dimensions: 190 x 92.5 x 45 mm
• Weight: 0.14 kg
• Includes mounting kit

30 30 dagar öppet köp 3 3 års Thomann garanti

• Tillgänglig sedanJuli 2025
• Artikelnummer 614699
• försäljningsenhet1 Styck
• Amount Of Channels 2
• AD Conversion Yes
• DA Conversion No
• Max. Resolution 32 bit
• Max. sampling rate 96 kHz
• S/PDIF Connecor No
• AES/EBU Connector No
• ADAT No
• Word clock No
• Number of analog inputs 2
• Number of Analog Outputs 0
• Headphone connection No
• Network Protocol Dante
• Connector RJ45
• Width 190 mm
• Depth in mm 92 mm
• Height 45 mm
• Weight 0,145 kg
• Mounting Height 0 U
• 19″ Rackkit No
• Input Channels 2
• Output Channels 0
• Digital Inputs 0
• Digital Outputs 0
• Special Features Assembly
